Industrial Ovens, Drying Ovens

Industrial lab ovens for batch processing


Our industrial heating and drying ovens are designed to test the limits of products or components under various degrees of heat, and in some cases, drying. Reproducible results plus the product quality connected to it, minimum space requirements, short processing times and a high level of productivity are the requirements in all industrial production areas. Your components and materials can be reliably, quickly and energy-efficiently heat-treated at temperatures of up to 400°C with HeatEvent Heating and Drying Ovens. In this way, you can manufacture excellent products 24/7.

HeatEvent provides the highest interior volume with the smallest footprint. Thanks to iE3 motors, improved insulation and the reliable door-sealing concept, the ovens operate with maximum energy efficiency. Our industrial ovens are equipped as standard with the digital SiMPAC® measurement and control system and the innovative WEBSeason® user interface. This provides for simple operation and monitoring of the heating and drying oven, the creation of complex temperature programs and the automation of processes in accordance with AMS 2750E or CQI-9.

Oven Quote

Features & Benefits
  • Smallest footprint with the large workspace
  • Superior temperature distribution and uniformity
  • Shorter processing time with fast temperature transition rates
  • Innovative WEBSeason® interface
  • Supports large product loads
  • Easy access panels for serviceability

  • Specifications
  • Dimensions
  • Communications

Size 8 to 285 cu. ft.
Larger sizes are available
Temperature Ranges Up to +300°C
Other temperature ranges available


  Interior Workspace Dimensions
(WxDxH)
Exterior Dimensions
(WxDxH)
60/60
8 cu. ft.
24" x 24" x 24"
(60cm x 60cm x 60cm)
39" x 63" x 37"
(100cm x 159cm x 94cm)
60/90
12 cu. ft.
24" x 35" x 24"
(60cm x 90cm x 60cm)
39" x 75" x 37"
(100cm x 189cm x 94cm)
75/125
25 cu. ft.
30" x 49" x 30"
(75cm x 125cm x 75cm)
67" x 85" x 47"
(171cm x 215cm x 119cm)
100/150
51 cu. ft.
39”W x 59”D x 39”H
(100cm x 150cm x 100cm)
77”W x 94”D x 57”H
(196cm x 240cm x 144cm)
125/200
109 cu. ft.
49”W x 79”D x 49”H
(125cm x 200cm x 125cm)
87”W x 114”D x 67”H
(221cm x 290cm x 169cm)
150/200
158 cu. ft.
 59"W x 79"D x 59"H
(150cm x 200cm x 150cm)
 97"W x 114"D x 76"H
(246cm x 290cm x 193cm)
200/200
285 cu. ft.
 79"W x 79"D x 79"H
(200cm x 200cm x 200cm)
 117"W x 114"D x 96"H
(297cm x 290cm x 244cm)

Touch Screen Controller
  • WebSeason® Controller Interface - Program, Control and Monitor your testing
    Up to six users can simultaneously use any web-based device (such as smart phones, tablets, or laptops) to connect to the controller remotely, in their own language. In addition, any user has remote access to view information, such as remaining test time, number of cycles, current steps and actual values, as well as warning and alarm notices.TCP/IP protocol.


>
